Low-pressure endoscopy using the gel immersion method facilitates endoscopic reduction of a Morgagni hernia

A Morgagni hernia is an uncommon diaphragmatic hernia. Complications such as obstruction and resulting necrosis can be life-threatening, and surgery is mandatory. However, minimally invasive treatments are preferred for elderly patients with comorbidities. Although treatment of a Morgagni hernia by endoscopic reduction has been reported [1], hyperinflation during colonoscopy may increase intraluminal pressure and exacerbate incarceration. In the presence of an incarcerated Morgagni hernia, bowel preparation for colonoscopy is impossible, and securing the visual field is difficult. Gel immersion endoscopy has been reported to be useful for securing the visual field and decreasing intraluminal pressure [2] [3].

An 84-year-old woman with multiple cardiac comorbidities was hospitalized with epigastric pain and vomiting. A computed tomography scan showed prolapse of the transverse colon into the mediastinum and was consistent with obstruction due to a Morgagni hernia ([Fig. 1]). Bearing in mind the patient’s comorbidities, surgical treatment was considered high risk. However, conservative treatment did not improve the obstruction. Colonoscopy without bowel preparation was performed ([Video 1]). It was difficult to secure the visual field because of fecal impaction. However, by injecting gel (Viscoclear; Otsuka Pharmaceutical Factory, Tokushima, Japan), a transparent space between the tip of the endoscope and the intestinal wall was created and maintained, enabling endoscope insertion without gas insufflation while keeping the intraluminal pressure at a low level. A luminal constriction was found in the transverse colon, thought to be at the orifice of the Morgagni hernia ([Fig. 2]). After insertion of the endoscope beyond the constriction, residual fluid and gas in the dilated lumen were aspirated ([Fig. 3]). This reduced the herniation ([Fig. 4]) and enabled endoscope insertion to the ileocecal valve, confirmed by X-ray fluoroscopy ([Fig. 5]).

Fig. 1 A computed tomography scan showed prolapse of the transverse colon into the mediastinum and was consistent with obstruction due to a Morgagni hernia. a axial view; b coronal view

Video 1 A Morgagni hernia treated by means of endoscopic reduction with low-pressure endoscopy using the gel immersion method.

Fig. 2 A luminal constriction was found in the transverse colon, which was thought to be at the orifice of the Morgagni hernia.

Fig. 3 After insertion of the endoscope beyond the constriction, fecal retention was observed. Residual fluid and gas in the dilated lumen were aspirated, and the lumen collapsed.

Fig. 4 The collapsed lumen allowed endoscope insertion proximally, which reduced the herniation.

Fig. 5 The endoscope was inserted to the ileocecal valve, and hernia reduction was confirmed by X-ray fluoroscopy.

Low-pressure endoscopy using the gel immersion method facilitates endoscopic reduction as a minimally invasive treatment of a Morgagni hernia.

Endoscopy_UCTN_Code_CCL_1AD_2AJ

Competing interests

Tomonori Yano has patents for the dedicated electrolyte-free gel and received honoraria from Otsuka Pharmaceutical Factory. No other authors have personal financial relationships with a commercial entity producing healthcare-related products and/or services relevant to this article.

• References

• 1 Yoshida S, Hirama K, Mizuno Y. et al. A case of Morgagni hernia in an elderly patient that was successfully treated by endoscopic reduction of the herniated transverse colon followed by elective laparoscopic mesh repair. J Abdom Emerg Med 2020; 40: 559-562
• 2 Yano T, Nemoto D, Ono K. et al. Gel immersion endoscopy: a novel method to secure the visual field during endoscopy in bleeding patients (with videos). Gastrointest Endosc 2016; 83: 809-811
• 3 Yano K, Yano T, Nagayama M. et al. Hemostasis of an actively bleeding lesion at the ileocecal valve by low-pressure endoscopy using the gel immersion technique. VideoGIE 2021; 6: 184-186
